PlatformDesktop
Product Family AMD Ryzen™ Processors
Product Line AMD Ryzen™ 9 Desktop Processors
# of CPU Cores 12
# of Threads 24
Max. Boost Clock Up to 5.6GHz
Base Clock4.7GHz
L1 Cache 768KB
L2 Cache 12MB
L3 Cache 64MB
Default TDP 170W
Processor Technology for CPU Cores TSMC 5nm FinFET
Unlocked for Overclocking Yes
CPU Socket AM5
Thermal Solution (PIB) Not included
Max. Operating Temperature (Tjmax) 95°C
Launch Date

Connectivity
Memory Channels 2
Max Memory Speed
1x1R
5200 MT/s
1x2R
5200 MT/s
2x1R
3600 MT/s
2x2R
3600 MT/s

Graphics Capabilities
Graphics Model
AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
GPU Base 400 MHz

Supported Technologies
AMD EXPO™ Technology
AMD Ryzen™ Technologies
