Clock: GPU / Memory Boost Clock*: Up to 2970 MHz / 20 Gbps Game Clock**: 2400 MHz / 20 Gbps Key Specification AMD Radeon™ RX 9070 XT GPU 16GB GDDR6 on 256-Bit Memory Bus AMD RDNA™ 4 Architecture 64 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators) Microsoft® DirectX® 12 Ultimate PCI® Express 5.0 Support 2x 8-pin Power Connectors 3x DisplayPort™ 2.1a, 1x HDMI™ 2.1b Key Features Polychrome SYNC Triple Fan Design Stylish Metal Backplate Striped Ring Fan Reinforced Metal Frame Air Deflecting Fin Ultra-fit Heatpipe Super Alloy Graphics Card

Manufacturer: Asrock

SKU: CGC0191

Manufacturer part number: RX9070XT SL 16G

Availability: Out of stock

Full Description
Specifications
Tags

Graphics Engine
- AMD Radeon™ RX 9070 XT
Bus Standard
- PCI^® Express 5.0 x16
DirectX
- 12 Ultimate
OpenGL
- 4.6
Memory
- 16GB GDDR6
Engine Clock
- Boost Clock: Up to 2970 MHz*
- Game Clock: 2400 MHz**

*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
Stream Processors
- 4096
Memory Clock
- 20 Gbps
Memory Interface
- 256-bit
Resolution
- Digital Max Resolution: 7680 x 4320
Interface
- 3x DisplayPort 2.1a
- 1x HDMI 2.1b
HDCP
- Yes
Multi-view
- 4
Recommended PSU
- 800W
Power Connector
- 2x 8-pin
Accessories
- 1x Quick Installation Guide
Dimensions
- 298 x 131 x 58 mm, 2.9-slot
Net Weight
- 1155 g

Products specifications

Attribute name	Attribute value
Graphic Memory	16GB
No. of Fans	3
Gpu Chipset	9070
Consumption	300w
