Intel Raptor Lake
Manufacturer: Intel
SKU: CCP0095
Availability: Out of stock
€428.81 excl tax

CPU Specifications
Total Cores 24
# of Performance-cores8
# of Efficient-cores16
Total Threads 32
Max Turbo Frequency 5.80 GHz
Intel® Thermal Velocity Boost Frequency 5.80 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 5.70 GHz
Performance-core Max Turbo Frequency 5.40 GHz
Efficient-core Max Turbo Frequency 4.30 GHz
Performance-core Base Frequency3.00 GHz
Efficient-core Base Frequency2.20 GHz
Cache 36 MB Intel® Smart Cache
Total L2 Cache32 MB
Processor Base Power 125 W
Maximum Turbo Power 253 W
Supplemental Information
Embedded Options Available No
Memory Specifications
Max Memory Size (dependent on memory type) 128 GB
Memory Types Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth 89.6 GB/s
Expansion Options
Direct Media Interface (DMI) Revision4.0
Max # of DMI Lanes8
Scalability1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations ‡ Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes 20
Package Specifications
Sockets Supported FCLGA1700
Max CPU Configuration1
TJUNCTION 100°C
Advanced Technologies
Intel® Gaussian & Neural Accelerator 3.0
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Speed Shift Technology Yes
Intel® Thermal Velocity Boost Yes
Intel® Turbo Boost Max Technology 3.0 ‡ Yes
Intel® Turbo Boost Technology ‡ 2.0
Intel® Hyper-Threading Technology ‡ Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Volume Management Device (VMD) Yes
Security & Reliability
Intel® Standard Manageability (ISM) ‡ Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® AES New Instructions Yes
Secure Key Yes
Intel® OS GuardYes
Execute Disable Bit ‡ Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Products specifications
Attribute nameAttribute value
LGA/Socket TypeLGA1700
Integrated GraphicsNo
TDP250W
Cooling FanNo

Intel Core i9-13900KF 1700

€428.81 excl tax
