Get ultra-efficient with Intel Core Ultra desktop processors that improve both performance and efficiency so your PC can run cooler, quieter, and quicker. Core & Threads 14 cores (6 P-cores + 8 E-cores) and 14 threads

Manufacturer: Intel

SKU: CCP0130

Manufacturer part number: Core Ultra 5 245KF

Availability: 2 in stock

€276.27 excl tax

Qty:

Full Description
Specifications
Tags

CPU Specifications

Total Cores 14

# of Performance-cores 6

# of Efficient-cores 8

Total Threads 14

Max Turbo Frequency 5.2 GHz

Performance-core Max Turbo Frequency 5.2 GHz

Efficient-core Max Turbo Frequency 4.6 GHz

Performance-core Base Frequency 4.2 GHz

Efficient-core Base Frequency 3.6 GHz

Cache

24 MB Intel® Smart Cache

Total L2 Cache 26 MB

Processor Base Power 125 W

Maximum Turbo Power 159 W

Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes

AI Software Frameworks Supported by CPU

OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

CPU Lithography TSMC N3B

Memory Specifications

Max Memory Size (dependent on memory type) 192 GB

Memory Types Up to DDR5 6400 MT/s

Maximum Memory Speed 6400 MHz

Max # of Memory Channels 2

NPU Specifications

NPU Name^‡Intel® AI Boost

NPU Peak TOPS (Int8) 13

Sparsity Support Yes

Windows Studio Effects Support Yes

AI Software Frameworks Supported by NPU

OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

Direct Media Interface (DMI) Revision 4

Max # of DMI Lanes 8

Intel® Thunderbolt™ 4 Yes

Scalability 1S Only

PCI Express Revision 5.0 and 4.0

PCI Express Configurations ^‡

Up to 1x16+2x4, 2x8+2x4, 1x8+4x4

Max # of PCI Express Lanes 24

Package Specifications

Sockets Supported FCLGA1851

Thermal Solution Specification PCG 2020A

Max Operating Temperature 105 °C

Advanced Technologies

Intel® Volume Management Device (VMD) Yes

Intel® Gaussian & Neural Accelerator 3.5

Intel® Thread Director Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Technology ^‡ 2.0

Intel® 64 ^‡ Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Security & Reliability

Intel® Standard Manageability (ISM) ^‡ Yes

Intel® Control-Flow Enforcement Technology Yes

Intel® AES New Instructions Yes

Secure Key Yes

Intel® Trusted Execution Technology ^‡ Yes

Execute Disable Bit ^‡ Yes

Intel® OS Guard Yes

Intel® Boot Guard Yes

Mode-based Execute Control (MBEC) Yes

Intel® Virtualization Technology (VT-x) ^‡ Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ^‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ^‡ Yes

Products specifications

Attribute name	Attribute value
TDP	190W
LGA/Socket Type	LGA1851
Integrated Graphics	No
Cooling Fan	No
Consumption	160w
