Printing
Print Method Direct Thermal
Print Speed 260m/s
Resolution 640dots/line
Printing Width 80mm(max)/72mm(default)
Paper separator(option) 48mm/52mm/56mm/64mm/68mm/76mm/80mm
Memory
Input buffer 256kbytes
NV Flash 256kbytes
Fonts
Font A 12x24
Font B 9x17
Chinese GB18030,BIG5 24x24dots
Japanese/Korea Support
User-defined Support
Barcode
1D UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/
CODABAR/CODE93/CODE128

2D QR Code
Detection
Sensors Paper out, cover open, cutter jam,paper jam and black
mark detection(Optional)

Power Supply
Input AC 100V-240V 50/60HZ
Output DC 24V/2.5A
Paper
Paper Type Thermal Receipt Paper
Paper Width 48mm/52mm/56mm/64mm/68mm/76mm/80mm
Paper Thickness 0.06~0.08mm
Roll Dia Max. Ø 83 mm
Paper Load Easy paper loading
Paper Cut Manual tear or Auto-cutter
Physical Charateristics
Working Condition 0°C~45°C, 10%~80%RH
Storage Condition -10°C-60°C,10%~90%RH
Dimensions 184(D)x143(W)x148(H)mm
Net weight 2.25kg Gross weight 2.4kg
Reliability
Printing head 150KM
Cutter 1.5million
Accessories
data cable,power adaptor,power code,paper roller,CD,manual,
paper separator(option)

OS
Emulation ESC/POS
Driver Windows XP /Vista/ Win7/Win8 /Win10/Win 2000/Win CE/
OPOS/JPOS
