CAP

• Material:Aluminum and plastic

• Display Orientation:Software adjustable Default, +90, +180, and -90 Degrees

• Display Panel Active Area:1.54" (39.1mm)

• Display Resolution:240 x 240 px

• Display Brightness:300 cd/m²

• Display Panel Type:Transmissive TFT, 262K color

WATER BLOCK

• Dimensions:Diameter: 74.7mm H: 55.97mm

• Material:Block: Copper Housing: Plastic

PUMP

• Motor Speed:800 - 2,800 ± 300RPM

• Power:12V DC, 0.3A

RADIATOR

• Dimensions:123 x 275 x 30mm

• Material:Aluminum

TUBE

• Length:400mm

• Material:Ultra-low Evaporation Rubber with Nylon Braided Sleeve

FAN

• Model:F120 RGB Core Fans

• Quantity:2

• Dimension:120 x 120 x 26mm

• Speed:500-1,800 ± 180 RPM

• Air Flow:78.86 CFM

• Air Pressure:2.57 mm H2O

• Noise:33.88 dBA

• Bearing:Fluid Dynamic Bearing

• Power Consumption:12V DC, 0.2 A, 2.4W

• Connector:4-pin PWM

• Life:60,000 hours / 6 Years

RGB CONTROLLER

• Dimensions:63.2 x 53.2 x 12.8mm

• Weight:52.8g

• Mounting:Magnet and 3M Dual Lock

• Connection Cables:1x USB 2.0 internal connector 1x SATA power cable

• Input Connector:12V DC / 2.6A

• RGB Lighting Channels:3

• Output Channel Voltage:5V DC

• NZXT RGB Channel Output LED Qty.:Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels

COMPATIBLE SOCKET & CPU

• Intel:Intel Socket LGA 1700 & 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron

• AMD:AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper

GENERAL
