With true double-conversion online UPS design, PowerWalker VFI 1000-3000 C LCD provides powerful and overall protection to your sensitive devices. It can accept wide input voltage for harsh environment. It offers full protection for critical devices such as sensitive servers, network/telephone communication systems as well as for industrial applications.

Manufacturer: Powerwalker

SKU: PUP0049

Availability: Out of stock

€486.39 excl tax

Qty:

Full Description
Specifications

General features
Type	Online
Power capacity	2000VA / 1600W
Output Power Factor	0.80
Input
Input Voltage Range	Voltage Range Low Line Transfer 110-160VAC ± 5% depending on load level Voltage Range Low Line Comeback 125-175VAC ± 5% depending on load level Voltage Range High Line Transfer 300VAC ± 5% Voltage Range High Line Comeback 290VAC ± 5VAC
Input PF	≥ 0.99 at full load
Frequency Range	40Hz - 70Hz
Frequency (Synchronized Range)	47Hz - 53Hz or 57Hz - 63Hz
Output
Nominal Output Voltage	200/208/220/230/240 VAC
Pure Sine Wave	Yes
THDv	≤3% Full Linear Load; ≤6% Non-Linear Load
Voltage Regulation (Bat. Mod.)	±1%
Frequency (Battery Mode)	±0,3Hz
Technical details
Load Crest Ratio	3:1
Transfer Time [AC to Battery]	0ms
Transfer Time [Inverter to Bypass]	4ms
Generator support	Yes
Overload Capacity	Line: Bypass @>105%; BAT: 10min @105%-110%; 1min @110%-130%; 3s @>130%
External Battery Connection	Yes
Charger	1A
Fan Logic	Always on, automatic speed control
LCD Indicators	UPS status, Load level, Battery level, Input/Output voltage, AC mode, battery mode, Bypass mode, fault conditions
Efficiency
LINE mode full Load	89.0%
BATTERY mode full Load	87.0%
Batteries and autonomy time
Batteries	4x 12V/9Ah
DC Voltage	4 x 12V
Recharge Time	9h to 90%
Full Load Backup Time	4min
Half Load Backup Time	11.5min
Connections and communication
IEC C13 Outlet	4
Input	C14-UK
Software	ViewPower
USB port	Yes
RS-232 Port	Yes
Extension Slot	Yes, 1
Environment
Noise Level	< 50dB
Temperature	0°C – 40°C
Humidity	20% - 90% RH (non-condensing)
Logistics
IEC 62040-3 classification	VFI-SS-111
Package Content	UPS, Manual, USB Cable, Input Power Cable
Manual Languages	EN/ES/PL
EAN	4260074977127
Width	145 mm
Height	220 mm
Depth	397 mm
Weight	17 kg
Giftbox - Width	230 mm
Giftbox - Height	325 mm
Giftbox - Depth	472 mm
Giftbox - Weight	18.5 kg
Pcs. per box	1

Products specifications

Attribute name	Attribute value
UPS Type	Online
Output Connections	C13
UPS Power	Up to 2000 VA
UPS Features	Tower, LCD, Pure Sinewave
