General Feature
Application Client PCs

Capacity
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 4.0 x4, NVMe 1.3c
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 9.0 g Weight
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Elpis Controller
Cache Memory Samsung 1GB Low Power DDR4 SDRAM
TRIM Support Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0) TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes
Performance
Sequential Read Up to 7,000 MB/s * Performance may vary based on system hardware & configuration

Sequential Write Up to 5,000 MB/s * Performance may vary based on system hardware & configuration

Random Read (4KB, QD32) Up to 1,000,000 IOPS * Performance may vary based on system hardware & configuration

Random Write (4KB, QD32) Up to 1,000,000 IOPS * Performance may vary based on system hardware & configuration

Random Read (4KB, QD1) Up to 22,000 IOPS * Performance may vary based on system hardware & configuration

Random Write (4KB, QD1) Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
*Average: 6.2 W *Maximum: 8.9 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)
