Full Description
Specifications
Tags

General Feature

ApplicationClient PCs, Game Consoles
Capacity2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form FactorM.2 (2280)
InterfacePCIe Gen 4.0 x4, NVMe 2.0
Dimension (WxHxD)80 x 22 x 2.3 mm
WeightMax 9.0g Weight
Storage MemorySamsung V-NAND 3-bit MLC
ControllerSamsung in-house Controller
Cache MemorySamsung 2GB Low Power DDR4 SDRAM

Special Feature

TRIM SupportSupported
S.M.A.R.T SupportSupported
GC (Garbage Collection)Auto Garbage Collection Algorithm
Encryption SupportAES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN SupportNot supported
Device Sleep Mode SupportYes

Performance

Sequential ReadUp to 7,450 MB/s * Performance may vary based on system hardware & configuration
Sequential WriteUp to 6,900 MB/s * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD32)Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD1)Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4 KB, QD1)Up to 80,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level)*Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage3.3 V ± 5 % Allowable voltage
Reliability (MTBF)1.5 Million Hours Reliability (MTBF)
Operating Temperature0 - 70 ℃ Operating Temperature
Shock1,500 G & 0.5 ms (Half sine)
