The world’s favorite SSD

Manufacturer: Samsung

SKU: CSS0047

Manufacturer part number: MZ-77E500B/EU

GTIN: 8806090545924

Availability: 18 in stock

ApplicationClient PCs
Capacity500 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor2.5 inch
InterfaceSATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD)100 X 69.85 X 6.8 (mm)
WeightApporx. 45.0g Weight
Storage MemorySamsung V-NAND 3bit MLC
ControllerSamsung MKX Controller
Cache MemorySamsung 512 MB Low Power DDR4 SDRAM

TRIM SupportTRIM Supported
S.M.A.R.T SupportS.M.A.R.T Supported
GC (Garbage Collection)Auto Garbage Collection Algorithm
Encryption SupportAES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN SupportWorld Wide Name supported
Device Sleep Mode SupportYes

Sequential ReadUp to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential WriteUp to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4 KB, QD32)Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD32)Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4 KB, QD1)Up to 13,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4 KB, QD1)Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Average Power Consumption (system level)Average: 2.2 W *Maximum: 3.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage5V ± 5% Allowable voltage
Reliability (MTBF)1.5 Million Hours Reliability (MTBF)
Operating Temperature0 - 70 ℃ Operating Temperature
Shock1,500 G & 0.5 ms (Half sine)
