Following the well-established legacy of the Seasonic FOCUS Series, the FOCUS GX White Series has been upgraded to comply with the ATX 3.1 and PCIe 5.1 standards. It offers a complete range of power supplies from 750W to 1000W, all within a compact 140mm depth. Each unit features a 135mm fan, a 12V-2×6 cable, our new OptiSink technology and a stunning white finish. These units are designed to be perfect allies in powering the latest high-power graphics cards and processors available on the market.
Manufacturer: Seasonic
SKU: CPO0139
Manufacturer part number: / SRP-FGX851-A5A32SF
Availability: 3 in stock
€151.27 excl tax
80PLUS®Gold
Cybenetics Efficiency LevelTBA
Cybenetics Noise LevelTBA
Form FactorATX/EPS
Fan InformationFan Size135 mm
Fan ControlDigital Hybrid Fan Control
Fan BearingFluid Dynamic Bearing
Life Expectancy50,000 hours at 40 °C, 15 % - 65 % RH
Cable InformationModularityFully Modular
Cable typeIndividual White Cables with Braided Pattern
Electrical FeaturesOperating Temperature0 - 50 °C
MTBF @ 25 °C, excl. fan100,000 hours
AC InputFull Range
ProtectionOCP, OPP, OTP, OVP, SCP, UVP
Safety and EnvironmentalSafety and EMCBSMI, CB, CCC, CE, cTUVus, EAC, FCC, TUV
Environmental ComplianceEnergy Star, ErP Lot 6, REACH, RoHS, WEEE
Warranty10 Years
Power Output
AC Input100 V - 240 V
11 - 5.5 A
50 Hz - 60 Hz
DC OutputRail+3.3 V+5 V+12 V-12 V+5 VSB
Maximum Power20 A20 A70 A0.3 A3 A
 100 W840 W3.6 W15 W
 Total continuous power850 W
Products specifications
Attribute nameAttribute value
EfficiencyGold
Wattage850w
PSU Form FactorATX
