More Information
P/N
CA-1Q9-00S1WN-00
SERIES
S Series
MODEL
S100 TG
CASE TYPE
Micro Case
DIMENSION (H X W X D)
411 x 220 x 441 mm
(16.18 x 8.66 x 17.36 inch)
NET WEIGHT
6.1 kg / 13.45 lbs.
SIDE PANEL
Tempered Glass x 1
COLOR
Exterior & Interior : Black
MATERIAL
SPCC
COOLING SYSTEM
Rear (exhaust) :
120 x 120 x 25 mm fan
(1000rpm, 16 dBA)
DRIVE BAYS
-ACCESSIBLE
-HIDDEN

-
2 x 2.5” (HDD Bracket); 2 x 3.5“ or 2 x 2.5” (HDD Rack);
EXPANSION SLOTS
4
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
I/O PORT
1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio,
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
3 x 120mm, 2 x 140mm
Top:
2 x 120mm, 2 x 140mm, 1 x 200mm
Rear:
1 x 120mm,
RADIATOR SUPPORT
Front:
1x 240mm, 1 x 280mm
Top:
1 x 240mm, 1x 280mm
Rear:
1 x 120mm,
CLEARANCE
CPU cooler height limitation: 165mm
PSU length limitation: 160mm
VGA length limitation: 330mm
