P/N PS-TPG-0850FPCGxx-R
Short P/N TPG-0850F-R
Model TPG-850AH3FSG-R
Type ATX 12V v2.4 and EPS v2.92
Max. Output Capacity 850W
Peak Output Capacity 1020W
Color Black
Dimension （ W / H / D ） 150mm(W) x 86mm(H) x 160mm(D)
PFC （Power Factor Correction） Active PFC
Power Good Signal 100-500 msec
Input Current 12A
Input Frequency Range 50Hz - 60Hz
Input Voltage 100V – 240V~
Operating Temperature 0°C to + 50°C
Operating Humidity 20% to 90%,non-condensing
Storage Temperature -40°C to + 70°C
Storage Humidity 20% to 95%, non-condensing
Cooling System 14cm hydraulic bearing fan
Efficiency Meet 80 PLUS®Gold at 115Vac input.
MTBF 120,000 hrs minimum
Safety Approval CE/cTUVus/TÜV SÜD/FCC/CCC/BSMI/EAC
Protection OVP,SCP,OPP,UVP,OTP,OCP
PCI-E Connector 6
