5× 10/100/1000Mbos Auto-Negotiation RJ45 port, supporting Auto-MDI/MDIX Green Ethernet technology saves power IEEE 802.3X flow control provides reliable data transfer Plastic casing, desktop or wall-mounting design Plug and play, no configuration needed Fanless design ensures quiet operation

Manufacturer: Tp-Link

SKU: NSW0033

Manufacturer part number: LS1005G

GTIN: 6935364085506

Availability: Out of stock

Full Description
Specifications
Tags

HARDWARE FEATURES
Standards and Protocols IEEE 802.3i/802.3u/ 802.3ab/802.3x
Interface 5× 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
Fan Quantity Fanless
External Power Supply External Power Adapter (Output: 5VDC/0.6A)
Dimensions ( W x D x H ) 3.5 × 2.8 × 0.9 in. (90 × 72 × 23 mm)
Max Power Consumption 3.7W
Max Heat Dissipation 12.617 BTU/h
PERFORMANCE
Switching Capacity 10 Gbps
Packet Forwarding Rate 7.4 Mpps
MAC Address Table 2K
Packet Buffer Memory 1.5 Mb
Jumbo Frame 16 KB
SOFTWARE FEATURES
Advanced Features Green Technology
802.3X Flow Control
Back Pressure
Transfer Method Store and Forward
OTHERS
Certification CE, FCC, RoHS
Package Contents 5-Port 10/100/1000Mbps Desktop Switch
Power Adapter
Installation Guide
Environment Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing

Products specifications
