HARDWARE FEATURES
Plug Type EU, UK, US,FR
Standards and Protocols HomePlug AV2, HomePlug AV, IEEE 1901,
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Interface 2 * Gigabit Ethernet Port, Power Socket
Button Pair
Power Consumption Maximum: 5.8 W (230V/50Hz)
Standby: 0.5 W (230V/50Hz)
LED Indicator Power, Powerline, Ethernet
Dimensions ( W x D x H ) 5.2×2.8×1.7 in. (131×72×42 mm)
Range Up to 300 meters/1000 feet over existing electrical wiring
Power Output to Integrated Socket 13 A
Compatibility Compatible with all AV2000, AV1200, AV1000, AV600, AV500 &
AV200 powerline adapters
Transmission Speeds Powerline: up to 2000 Mbps
Ethernet: 10/100/1000 Mbps
SOFTWARE FEATURES
Quality of Service ToS
Supports up to 4-level type QoS
Support up to 8-level VLAN priority
Security 128-bit AES Encryption
Modulation Technology OFDM
OTHERS
Certification CE, RoHS
Package Contents  AV2000 2-port Gigabit Passthrough Powerline Adapter, TL-PA9020P * 2
 2-meter RJ-45 Ethernet Cable * 2
 Quick Installation Guide
System Requirements Windows 8.1/8/7/Vista/XP, Mac OS, Linux
Environment  Operating Temperature: 0°C~40°C (32°F~104°F)
 Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
 Operating Humidity: 10%~90% non-condensing
 Storage Humidity: 5%~90% non-condensing
