The internal structure design of the radiators was executed with low flow restriction in mind, providing no unnecessary stress on the rest of the cooling loop. This means you will be able to add multiple radiators to your cooling loop using only a single pump (D5 or DDC). The radiators are also airflow-friendly and low-restriction, allowing lower fan speed operation to achieve the same performance. Low airflow restriction keeps the case well-ventilated and allows other radiators in the case to breathe properly.

Manufacturer: Ekwb

SKU: CCW0153

Manufacturer part number: EK-QTM-SURF-S360-BK-EDITION

Availability: 2 in stock

€86.02 excl tax

Qty:

Full Description
Specifications
Tags

Technical and Material Specifications:

- High-grade 99.9% copper fins
- Copper H90 tubing
- Brass H62 end tank chambers
- Stainless Steel side plates
- Extruded Aluminum Black end piece covers
- Brass nickel-plated adapters and plugs
- Dimensions: 405 x 130 x 30mm (L x W x H)
- Weight: 0.95kg
- FPI: 20
- Port threads: 2x G1/4"
- Fan compatibility: 120x120x25mm fan
- Pressure tested: 1bar

Enclosed:

- EK-Quantum Surface S series radiator
- 12x M4x30mm for 25mm thick fans
- 12x M4x5mm for mounting the radiator directly to the case

Products specifications

Attribute name	Attribute value
Consumption	50w
