The PowerWalker VI 600-3000 SCL series offers a simple yet effective solution for PCs and other home applications. It is available with Type F (CEE 7/3), Type E (CEE 7/5) and Type G (BS 1363) outlets and features a microprocessor-controlled Automatic Voltage Regulator, which stabilizes voltage within a safe limit by switching to boost and buck modes. The series offers convenient touch panel which allows to scroll through most useful monitored parameters. All UPSs in this series can be turned on directly from battery (cold start function) and internal batteries can be charged in standby mode. This model comes with a USB port with HID support and can be monitored and controlled using the PowerWalker ViewPower software (available for download from our website) or directly using O/S' native drivers thanks to HID. To offer the best price-performance and to reduce environmental impact we provide the UPS without Software CD and USB cable.

Manufacturer: Powerwalker

SKU: PUP0112

Manufacturer part number: 10121158

Availability: 3 in stock

€216.08 excl tax

Qty:

Full Description
Specifications

General characteristics
Tip Line-Interactive
Power capacity 3000VA / 1800W
Output power factor 0.60
Input
Input voltage Interval 162-290 VAC
Frequency range 50Hz or 60Hz (self-adaptive)
Frequency (Synchronized Range) 50Hz or 60Hz
Output
Rated output voltage 230 VAC
Voltage regulation (Bat. Mod.) ±10%
Frequency (Battery Mode) ±1Hz
Technical details
Transfer Time [AC to Battery] 2-6ms
Overload Capacity N/A
Charger 1A
Protection Overload, discharge and overcharge protection
Efficiency
LINE mode full Load 94.0%
Batteries and battery life
Battery 2x 12V / 9Ah
DC Voltage 2 x 12V
Recharge Time 6h to 90%
Full Load Backup Time 0.7min
Half Load Backup Time 4min
Connections and communication
BS-1363 (Type G) UK Outlet 4
Input C20-UK
Software ViewPower
USB port gives
HID support gives
RS-232 Port gives
RJ-45/RJ-11 protection gives
Environment
Noise level < 40dB
Temperature 0°C – 40°C
Moisture 0% - 90% RH (non-condensing)
Logistics
Package Content UPS, Manual
Manual Languages EN / DE / FR / IT / ES / PT / PL / RU
EAN 4260074982305
Width 146 mm
Height 205 mm
Depth 397 mm
Weight 11.5 kg
Giftbox - Weight 14.5 kg
