Gen4 steps up to the arena with more than 55% improvement in random performance compared to 980 PRO. • With read and write speeds up to 7450/6900 MB/s² you’ll reach near max performance of PCIe® 4.0³ powering through for any use. • Give yourself some space with storage capacities from 1TB to 4TB. • Get power efficiency all while experiencing up to 50% improved performance per watt over the 980 PRO.⁴
Manufacturer: Samsung
SKU: CSS0105
Manufacturer part number: MZ-V9P4T0BW
Availability: 1 in stock
€305.93 excl tax
  • General Feature
    Application
    Client PCs, Game Consoles
    Capacity
    4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
    Interface
    PCIe Gen 4.0 x4, NVMe 2.0
    Dimension (WxHxD)
    3.15 x 0.87 x 0.091 inches
    Weight
    Max 0.02 lbs
    Form Factor
    M.2 (2280)
    Storage Memory
    Samsung V-NAND TLC
    Controller
    Samsung in-house Controller
    Cache Memory
    Samsung 4GB Low Power DDR4 SDRAM
  • Performance
    Sequential Read
    Up to 7,450 MB/s * Performance may vary based on system hardware & configuration
    Sequential write
    Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
    Random Read (4KB ,QD32)
    Up to 1,600,000 IOPS * Performance may vary based on system hardware & configuration
    Random Write (4KB ,QD32)
    Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
    Random Read (4KB ,QD1)
    Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
    Random Write (4KB ,QD1)
    Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
  • Environmental Specs
    Operating Temperature
    32°F - 158°F (0 - 70 ℃ Operating Temperature)
    Shock
    1,500 G & 0.5 ms (Half sine)
  • Weight
    Shipping Weight
    0.2
  • Software
    Management SW
    Magician Software for SSD management
  • Warranty
    Product
    5-year Limited Warrantyor 2400 TBW Limited Warranty
  • Special Feature
    TRIM Support
    Supported
    S.M.A.R.T Support
    Supported
    GC (Garbage Collection)
    Auto Garbage Collection Algorithm
    Encryption Support
    AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
    WWN Support
    Not supported
    Device Sleep Mode Support
    Yes
  • Environment
    Average Power Consumption (system level)
    *Average: 6.5 W*Maximum: 8.6 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
    Power consumption (Idle)
    Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
    Allowable Voltage
    3.3 V ± 5 % Allowable voltage
    Reliability (MTBF)
    1.5 Million Hours Reliability (MTBF)
  • Accessories
    Installation Kit
    Not Available

Products specifications
Attribute nameAttribute value
Storage Form FactorM.2
Storage Capacity4 TB
M.2 Bus Speedx4
Consumption15w
