| GENERAL FEATURES |
| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Tower |
| Power Capacity | 2000VA / 1800W |
| Output Power Factor | 0.90 |
| INPUT |
| Input Voltage Range | 176-300 VAC or 80-285 VAC in Bypass Mode |
| Max THDi | ≤5% |
| Frequency Range | 40Hz – 70Hz |
| Frequency (Synchronized Range) | 45Hz – 55Hz or 54Hz – 66Hz |
| OUTPUT |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 220/230/240 VAC |
| THDv | ≤2% @ 100% linear load, ≤5% @ 100% non-linear load |
| Voltage Regulation (Battery Mode) | ±2% |
| Frequency (Battery Mode) | ±0.05Hz |
| INPUT & OUTPUT CONNECTORS |
| Input Connector | C14-UK |
| Output Type | IEC – UK |
| IEC C13 | 4 |
| TECHNICAL DETAILS |
| LINE Mode Efficiency [%] (Full Load) | 90.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 4ms |
| Load Crest Ratio | 3:1 |
| Additional Features | ECO Mode Available, CVCF Mode Available, LCD Display, Circuit Breaker Reset, Generator Compatible, EPO – Emergency Power Off, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY |
| Batteries | 4x 12.0V/9.0Ah |
| DC Voltage | 4x 12.0V |
| Recharge Time | 4h to 90% |
| Full Load Backup Time [min] | 3.8 |
| Half Load Backup Time [min] | 11.0 |
| Charger | 1.5A |
| COMMUNICATION |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Software | WinPower |
| ENVIRONMENT |
| Noise Level | < 50dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 0% – 95% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS |
| Package Content | Input Power Cable, Manual, 2x IEC Cable, USB Cable, UPS |
| Manual Languages | DE, PL, EN |
| EAN | 4260074979374 |
| Product Dimensions (DxWxH) [mm] | 399 x 190 x 328 mm |
| Product Weight [kg] | 17.2 |
| Package Dimensions (DxWxH) [mm] | 500 x 324 x 464 mm |
| Package Weight [kg] | 19.6 |
| Pcs. per Outer Carton | 1 |
